Name:Prototype PCB assembly
Name:PCB contract manufacturing
Quantity:Prototype&Low Volume PCB Assembly, from 1 Board to 250,is for specialty, but we can handle orders up to 1000.
Type of Assembly:THD (Thru-Hole Device), SMT (Surface-Mount Technology), SMT & THD mixed, Double-sided SMT and THD assembly.
Solder Type:Water Soluble Solder Paste, Leaded and Lead-Free.
Components:Passives parts, smallest size 0201; BGA, uBGA, QFN, POP, and Leadless chips; Fine Pitch to 0.8Mils; BGA Repair and Reball; Part Removal and Replacement Connectors and terminals.
Bare Board Size:Smallest: 0.25x0.25 Inches; Largest: 20x20 Inches.
File Formats:Bill of Materials Gerber Files Pick-N-Place File(XYRS).
Type of Service:Turn-Key, Partial Turn-Key or Consignment.
Component Packaging:Reels,cut tape,Tube and tray,Loose parts and bulk.
Turn Time:Same Day Service to 10 day service.
Testing:X-ray Inspection AOI (Automated Optical Inspection) ICT (In-Circuit Test)/Functional Testing

Product Description

PCB Assembly Services – Contract Electronics Manufacturing (CEM)

Detailed Terms for PCB Assembly:

Technical Requirement Professional Surface-mounting and Through-hole soldering Technology
Various sizes like 1206, 0805, 0603 components SMT technology
ICT(In Circuit Test), FCT(Functional Circuit Test) technology
PCB Assembly With UL, CE, FCC, Rohs Approval
Nitrogen gas reflow soldering technology for SMT
High Standard SMT&Solder Assembly Line
High density interconnected board placement technology capacity
Quote&Production Requirement Gerber File or PCB File for Bare PCB Board Fabrication
BOM(Bill of Material) for Assembly, PNP(Pick and Place file) and Components Position also needed in assembly
To reduce the quote time, please provide us the full part number for each components, Quantity per board also the quantity for orders.
Testing Guide&Function Testing method to ensure the quality to reach nearly 0% scrap rate
OEM/ODM/EMS Services PCBA, PCB assembly: SMT & PTH & BGA
PCBA and enclosure design
Components sourcing and purchasing
Quick prototyping
Plastic injection molding
Metal sheet stamping
Final assembly
Test: AOI, In-Circuit Test (ICT), Functional Test (FCT)
Custom clearance for material importing and product exporting
